1800VersaUV

1.8 meters large format high quality UV printer

1800VersaUV

The 1800VersaUV is equipped with imported electronic components and an intelligent protective design, ensuring efficient and stable continuous printing production. At the same time, it offers exceptional high-precision image output. The key highlights of this machine are its outstanding stability andand price-performance.

Outstanding image performance

The 1800VersaUV is equipped with Ricoh Gen6 industrial printheads, delivering a minimum dot size of just 5pl for precise and consistent jetting performance. The intelligent control software supports three-level variable dot technology, enabling smooth and natural grayscale output with richer, more refined color transitions.

Low maintenance

The 1800VersaUV Equipped with a bidirectional printhead anti-collision system, a top-mounted 1.5L large-capacity ink cartridge that reduces ink replacement frequency, and imported electronic components that ensure long-term stable operation, it minimizes maintenance costs and downtime risks.

High stability

The 1800VersaUV dual fan cooling LED-UV lamp enables immediate drying, with automatic circulation of white ink and ink stirring to prevent sedimentation and nozzle clogging. The THK silent guide rails and long-lasting guide belts ensure high-speed material movement, greatly enhancing batch production efficiency.

Wide range of applications

The 1800VersaUV printer handles a diverse range of materials with ease. from advertising signage, exhibition panels, lightboxes, PVC sheets, acrylic, glass, wood, and metal, to personalized gifts and custom decorations, it delivers vivid, high-definition images every time. with industrial-grade performance and precise printing, the 1800VersaUV printer is ideal for outdoor advertising, commercial displays, packaging, home decoration, and custom projects, enabling efficient, flexible, and versatile production.

A wide field applications

Lightbox

Large billboard

Outdoor large format advertising

Airport Advertising

Decoration painting

Stretch Ceiling

Leather

Glass Decal

Get a quote

Whether you want to learn more about our products or need a customized solution, our expert team is here to support you.

Phone

Content *

Main Performance

Basic Color Configuration: CMYK

Optional Color Configurations:CMYK+White，CMYKLcLm

More optional depend Custom Demand

Maximum printing width: 1800mm(5'11") , It meets the requirements of most customers for large-format advertising printing.

Equipped with two rows of Ricoh Gen6 printheads, it significantly increases productivity while ensuring high precision.

The dual negative-pressure ink path control system ensures stable ink supply and consistent print quality. The large-capacity secondary ink tank allows continuous operation even when the main ink tank is low, preventing interruptions. The intelligent voice alert system notifies users of ink status in real time, making operation more convenient, reliable, and efficient.

The metal encoder scale offers high precision, excellent temperature and wear resistance, and strong contamination resistance, effectively enhancing carriage positioning stability; the dual guide rail structure combined with a professional towline layout ensures long-lasting and reliable operation.

The three-zone independently controlled negative pressure platform allows the suction areas to be adjusted according to the size of the printing media, ensuring the media remains flat and stable at all times.

Specifications

Model		1800VersaUV
Carriage moving approach		Belt
Print head		Ricoh G6
Basic and Max number of printheads		2--6
Maximum printheads number		6
Max Row of printheads		2
Used ink		TechJet RA-1000
Colors range		4 Colorsx2=CMYKx2
		6 Colorsx2=CMYKLcLmx2
		4 Colors +White=CMYK+White
		6 Colors+White=CMYKLcLm+white
Print mode	Print resolution	One row printhead printing speed	Two rows printhead printing speed	Color white color printing speed (Two-rows printheads)
Draft Mode	4Pass-720×600	37.2㎡/h	70.68㎡/h	23.56㎡/h
Standard mode	4Pass-720×600	20.5m²/h	36.9m²/h	14.43m²/h
Quality Mode	6Pass-720×900	14.35m²/h	26.6m²/h	9.92m²/h
High quality mode	8Pass-720×1200	10.86m²/h	20.47m²/h	7.7m²/h
Print Media	Max.width	1820mm（5.97F）
	Range	300-1810mm (0.98-5.94F）
	Thickness	0.3-2.5mm
	Max. diam of reel paper	Ф250mm
	Paper core	2 inches/3 inches
	Print margins	5mm on both sides
	Max. weight	80KG
RIP Software		ONYX、PhotoPrint、Caldera（Optional）
Data interface		USB2.0
Ink supply method		Vacuum negative pressure, continuous ink supply
Curing Method		Dual UV-LED Lampes
Printer weight		700KG
Dimension (W x D x H)		3010×900×1550mm
Power requirement		AC220V±10%，50/60HZ
Maximum power		3000W
Printable environment		Temperature 20-30 °C, humidity 40%-60%RH (non condensing)
Remark The above printing speed is the measured printing speed. The power consuption basicis on standby and normal print. *The printing speed basis just 4 colors and 6 colors model not involved the white and varnish.
